Ranked-score bar chart for a decision-family result

The shared chart for every MCDM ranking method: one horizontal bar per alternative, ordered best first, with the leading alternative picked out. It is generic over the method rather than tied to one, so AHP criterion weights and any ranking method's scores all draw through it. The score column is whatever the method reports as its headline quantity (a closeness coefficient, a net flow, a priority weight), so the axis is labelled from the result rather than hard-coded.

Usage

sframe_plot_decision_ranking(result, palette = c("web", "print"))

Arguments

result

A decision-family result list from run_analysis_plan(), carrying either scores and alternatives or a ranking table.

palette

One of "web" or "print". See sframe_brand().

Value

A ggplot2 object, or NULL when the result carries no ranking.

See also

run_analysis_plan()
